GC Capillary Columns
GENERAL OVERVIEW
Complete range of capillary columns from Agilent, Varian, SGE and Restek.
Highly Inert Capillary Columns with the Lowest Bleed Specifications - Guaranteed
· Accurate peak identification – achieving more reliable results
· Superior response for traces – better quantification
· Enhanced detector performance – increasing productivity and reducing costs
· Faster stabilization – longer instrument uptime, so increasing your productivity
The family of capillary columns provides a complete range of stationary phases suitable for industrial, toxicology, chemical
and environmental applications. The highly inert ultra-low bleed columns offer a bleed specification up to few-fold lower
than comparable competitive products.
Packed Column
All glass packed columns will fit Agilent/HP 5880, 5890, 5987 and 6890 GCs , Varian, Shimadzu, Perkin elmer and Thermo
Scientific.
All stainless steel columns are general configuration. You can carefully bend to fit most GCs.
Supplier of all Packed GC Columns for Agilent Technologies
Capillary Columns
Phase
100% Dimethyl Polysiloxane
An industry standard non-polar phase suitable for all routine analyses.
Robust high temperature non-polar phase for mass spectrometry applications.
100% polydimethylsiloxane non-polar columns for Simulated Distillation in the petroleum industry.
PONA A non-polar phase for PONA analysis.
Find out more on the Solvent Retention Time Tables Column Selection Guide from Agilent !
Column: DB-624 (Cat # 125-1334)
Column: DB-1 (Cat# 125-1034)
Column: DB-WAX (Cat # 125-7032)
Restek SIMDIST Column :
Get More Runs from Your SimDist Setup Using Next
Generation MXT®-1HT SimDist Columns
• Stable up to 450°C—lowest bleed for longest column lifetime.
• Reliably meet all ASTM D6352 and D7500 specifications.
• 100% dimethyl polysiloxane phase allows easy comparisons to historical data.
5% Phenyl Methylpolysiloxane
A general purpose phase with excellent high temperature characteristics. Popular columns used for a wide variety of
applications.
5% Phenyl Polysilphenylene-siloxane
MS-Premium, low bleed columns with a maximum temperature up to 370°C. Suitable for trace analysis of pesticides,
drugs, hydrocarbons and phenols. The column phase has been designed for robustness and is suitable for over 80% of
all routine analyses performed by chromatographers.
5% Phenyl Polycarborane-siloxane
Unique high temperature phase suited for simulated distillation and other petroleum applications. This column is the
highest temperature column available with a maximum temperature up to 480°C.
8% Phenyl Polycarborane-siloxane
Unique high temperature phase suited for the analysis of PolyChlorinated Biphenyl (PCB) congeners. The unique polarity
of this phase gives excellent separation of PCB congeners.
35% Phenyl Polysilphenylene-siloxane
MS-Premium, low bleed columns with a maximum temperature up to 370°C. Especially suited for trace analysis of
herbicides and aromatic columns.
Maximum temperature 370°C. Optimized for ECD. Ideal for the analysis of organochlorine herbicides and pesticides.
50% Phenyl Polysilphenylene-siloxane
MS-Premium, low bleed columns with a maximum temperature up to 370°C. Suited for a range of EPA methods and
pharmaceutical applications.
70% Cyanopropyl Polysilphenylene-siloxane
MS-Premium, low bleed columns with a maximum temperature up to 260°C. The polarity has been designed for Fatty Acid
Methyl ester (FAME) analysis.
90% Cyanopropyl Polysilphenylene-siloxane
MS-Premium, low bleed columns with a maximum temperature up to 280°C. Extremely polar phase for the fast separation
of
aromatics, perfumes, petrochemicals and other compounds that are difficult to resolve using conventional columns.
Polyethylene Glycol (PEG)
Gel-WAX is a robust, high temperature polar WAX phase. Less susceptible to damage by oxygen than conventional wax
columns.
A very polar phase suited to the analysis of alcohols, ketones and aldehydes. Also offers excellent separation of aromatic
isomers such as the xylene isomers.
Treated Polyethylene Glycol (PEG)
A very polar Nitroterephthalic acid modified PEG phase suited to the analysis of free fatty acids.
Fatty Acid / FAME Application Guide from Supelco Analytical
Analysis of Foods for Nutritional Needs
Include Free Fatty Acid Analysis, FAME Preparation, FAME Analysis
GC Columns by Phase (Equity®-1, Nukol™, Omegawax™, SP™-2380, SP-2560, SLB™-IL100)
14% Cyanoproylphenyl Polysiloxane
This phase has been selected with a polarity suited for the separation of organochlorine pesticides listed in the EPA 608
and 8081 methods.
50% Cyanopropylphenyl Polysiloxane
Useful for the analysis of Fatty Acid Methyl esters (FAMEs), carbohydrates, and neutral sterols.
Cyanopropylphenyl Polysiloxane (Volatiles)
A polar phase used for EPA volatile organics analysis (EPA 624, SW-846 8240/8260), alcohol analysis and for USP G43.
290/300°C maximum temperature.
A polar phase used for EPA volatile organics analysis (EPA 624, SW-846 8240/8260), alcohol analysis and for USP G43.
Permethylated Beta Cyclodextrin (Chiral)
Chiral columns for the separation of enatiomeric compounds found in natural products.
